Laser power |
1000W |
1500W |
2000W |
Mark |
||
Laser controllable power |
0-100% |
Note: The actual welding effect and thickness are related to the welding process and the proficiency of the operator |
||||
Laser controllable frequency |
50-3000Hz |
|||||
Laser controllable duty cycle |
0-100% |
|||||
Spot adjustment method |
automatic |
|||||
Welding mode |
Point shape, line shape, circle shape, double O shape, Triangle, figure eight |
|||||
cooling method |
water cooling |
|||||
Protective gas |
N2 Ar CO2 |
|||||
Spot adjustment method |
0.2-4mm |
|||||
Maximum thickness of welded plate |
carbon steel |
2 |
3 |
4 |
||
stainless |
2 |
3 |
4 |
|||
copper |
1 |
1.5 |
2 |
|||
aluminium |
1.5 |
2 |
2.5 |
|||
Welding speed |
≤50mm/s |
|||||
Way of working |
Continuous/modulation |
|||||
Dimensions(Length* width* depth) |
1300*600*1200mm |
|||||
Wire feeder diameter |
0.8/1.0/1.2 |
Equipment function introduction
Welding head design and function
1. The internal design is dexterous, and the good interactive control system expands the tolerance range of the processed parts and the width of the welding seam, and solves the problem of light
The disadvantage of small spots, better weld formation.
2. The shape is light, the design method of body engineering is adopted, and the grip is comfortable; it is easy to control with one hand, and the operation is simple and easy to use.
3. With multiple safety alarms, the light will be automatically locked after the workpiece is removed, and the safety is high.
4. The welding seam is beautiful, fast, no consumables, no welding marks, no discoloration, and no need for later polishing.
5. A variety of angle nozzles can be configured to meet the welding needs of different products.
Note: In order to protect the welded joints from oxidation and make the welded joints well protected, the shielding gas used should have chemical characteristics that do not cause harmful chemical reactions with the welded body.
Wire Feeder
1. This dual-drive wire feeder is an automatically driven mechanized wire feeder.
2. The shape is light and easy to operate.
3. Mainly used for automatic wire feeding for laser hand-held welding.
4. The system adopts microcomputer control, stepping reduction motor drive, high wire feeding precision and good repeatability.
5. Conveying steel wire and copper wire with specifications of 0.8m, 1.0m and 1.2mm.
Qingdao Xiang Star CNC Machinery Co., Ltd., is a high tech enterprise integral of the ability of R&D; Production; Sales.
Covers an area of 50 acres and plant area of 10,000 square meters; we located in No. 789, Guangda Road; Huangdao District; Qingdao City; Shandong Province; China.
As an original state owned restructured enterprise, we have more than 12 years experience in manufacturing and service in sheet metal processing industrial.
Especially in the field of manufacturing CNC (turret) punching machine and fiber laser cutting machine, we have deep technology accumulations.
Such as “Haier” ;“Sunrain”; “Midea” these big and influential companies are our company’s long term cooperative customers. Most of our customers are come from old customers or customers introductions.
Q1: I knew nothing about this machine, what kind of machine i should choose?
Answer: Just tell us what you want to do by using CNC laser machine, then let us give you perfect solutions and suggestions.
Q2: When I got this machine, but I don’t know how to use it. What should I do?
Answer: We will send video and English manual with the machine. If you still have some doubts, we can talk by telephone or skype and e-mail.
Q3: If some problems happen to this machine during warranty period, what should I do?
Answer: We will supply free parts during machine warranty period if machine have some problems. While we also supply free life long after-sales service. So any doubts, just let us know, we will give you solutions.
